Autel MaxiBAS BT508
Adaptive Conductance Battery Tester / Health Registration
The BT508 is powerful yet, lightweight battery and electrical system tester that uses Adaptive Conductance, an advanced battery analysis method, to produce a more accurate examination of the battery’s cold-cranking ability and reserve capacity, vital to determining a battery’s true health.
Features:
- Support in-vehicle and out-of-vehicle testing of passenger vehicle batteries
- Test 6- and 12-volt batteries: 100 – 2000 CCA
- Test 12- and 24- cranking/charging systems
- Test Flooded, AGM, AGM Spiral, EFB and GEL batteries
- Compatible with CCA, CA, SAE, EN, IEC, DIN, JIS and MCA
- One-touch battery registration
- Illustration instruction guides for battery positioning and testing
- Read and erase codes of all available systems
Why Choose Autel MaxiBAS BT508?
1. Fast Test: Deliver test results in seconds, ideal for busy shops;
2. Safe Connection: Safety clamps with reverse polarity protection;
3. Future Technologies: Support future battery and vehicle types via software updates;
4. Easy Share: Print out or email reports, easy to share with customers
5. Auto-Save: Saves test reports automatically for later view;
6. Wi-Fi Enabled: Wi-Fi connectivity to email test reports and update software.
| Item | Description |
| Connectivity |
|
| Input Voltage | 5 V DC |
| Working Current | < 150 mA at 12 V DC |
| CCA Range | 100 to 2000 A |
| Voltage Range | 6 to 36 V |
| Working Temperature | -10° to 50° C (14° to 122° F) |
| Storage Temperature | -20° to 60° C (-4° to 140° F) |
| Dimension (L x W x H) | 107 mm (4.21“) x 75 mm (2.95”) x 26 mm (1.02”) (clamp cable not included) |
| Weight | 320 g (0.7 lb.) |
